CNC Plasma Cutting Machine
Product Code : EL-CACLE-10873
CNC Plasma Cutting Machine (code EL-CACLE-10873) is an automatic CNC cutting machine used for plasma cutting of work-pieces up to 15 mm thick in a CAD and CAM laboratory. It offers cutting lengths of 0-500 mm or 500-1000 mm, a cutting width of 500-1000 mm and cutting speeds of 500-1000 mm/min, with an automatic height tracking system, ±0.02 mm accuracy and repeatability, a powder-coated finish and modular construction.
Get a quote: use the Add To Cart enquiry button below, or send your quantity and delivery location through the contact page.
Specifications
| Parameter | Detail |
|---|---|
| Automation grade | Automatic |
| Machine type | CNC cutting machine |
| Finish | Powder coated |
| Max. cutting length | 0-500 mm, 500-1000 mm |
| Max. cutting width | 500-1000 mm |
| Max. cutting speed | 500-1000 mm/min |
| Max. cutting thickness | 15 mm |
| Accuracy | ±0.02 mm |
| Repeatability precision | ±0.02 mm |
| Height control | Automatic height tracking system with fast-response automatic level control |
| Construction | Modular design for assembly and maintenance |
| Machine dimensions | 1400 × 800 × 1200 mm (L × W × H, approx.) |
| Machine weight | Approx. 185 kg |
| Product code | EL-CACLE-10873 |
| Manufacturer | Engineering Lab Equipment, Ambala, Haryana, India |
What Is the CNC Plasma Cutting Machine Used For?
Plasma cutting drives an electric arc through a jet of gas, turning the gas into a plasma hot enough to melt the work-piece along the cut line while the gas stream blows the molten material out of the kerf. In a CNC laboratory the student prepares the cutting path as a program, sets a work-piece of up to 15 mm thickness on the machine and lets it move the plasma torch along the path at a set speed between 500 and 1000 mm/min. The automatic height tracking system holds the torch height as it travels, so cut quality can be studied against speed and thickness.
What to Specify When Ordering
- Quantity — the number of machines required.
- Cutting length — the 0-500 mm or 500-1000 mm maximum cutting length range.
Frequently Asked Questions
What thickness can the CNC Plasma Cutting Machine cut?
The maximum cutting thickness is 15 mm, and the maximum cutting speed lies in the range of 500 to 1000 mm/min.
What cutting area is available?
Maximum cutting length is given in two ranges, 0-500 mm and 500-1000 mm, with a maximum cutting width of 500-1000 mm.
What accuracy does the machine have?
For this automatic CNC cutting machine, both the accuracy and the repeatability precision are ±0.02 mm.
What does the automatic height tracking system do?
It uses automatic level control with fast response characteristics to keep the cutting quality steady during high-speed cutting, holding the torch at a constant height above the work.
How large and heavy is the machine?
The machine measures approximately 1400 × 800 × 1200 mm (L × W × H) and weighs about 185 kg; it has a powder-coated finish and a modular design for assembly and maintenance.
OEM Manufacturer
Engineering Lab Equipment (Engineering Labs Equipment Pvt Ltd) builds the CNC Plasma Cutting Machine at its works in Saha, District Ambala, Haryana (Plot No. 43, Industrial Park, Sector 2, Growth Center). Its CAD and CAM laboratory machines and trainers go to engineering colleges, polytechnics, technical training institutes and research laboratories in India and abroad, and equipment can be made to an institution's own requirements. For tenders and OEM supply, see the Tenders/OEM page.
