Miniature Vertical Milling Machine
Product Code : EL-CACLE-10880
Miniature Vertical Milling Machine (code EL-CACLE-10880) is a vertical milling and drilling machine with a 550 W DC motor giving variable spindle speeds from 20 to 2500 rpm. Its tilting column allows drilling and milling at ±90° from vertical, the T-slotted table has metric graduated compound scales, and it offers 13 mm drilling, 30 mm face milling and 16 mm end milling capacity, an MT3 spindle taper and a digital readout.
Get a quote: use the Add To Cart enquiry button below, or send your quantity and delivery location through the contact page.
Specifications
| Parameter | Detail |
|---|---|
| Motor | 550 W DC motor with variable speed drive |
| Spindle speed | 20-2500 rpm |
| Feed speed | Adjustable to suit different work-pieces |
| Column | Tilting; drilling and milling at ±90° from vertical; head swivels ±90° |
| Spindle rotary angle | -45° to +45° |
| Working table | T-slots for clamping, metric graduated compound scales, extra wide cross table |
| Table adjustment | Adjustable gibs and adjustable stops |
| Readout | Digital readout display |
| Drill chuck fixing | Chuck arbor bolt tightens the drilling chuck through the spindle |
| Drilling feed | Rack and pinion |
| Safety guard | With micro switch |
| Gear drive | Straight gear drive mechanism |
| Lead screws | Metric |
| Switch | Start / stop switch incorporating emergency stop |
| Supplied with | 13 mm chuck accessory kit for adjusting and setting |
| Specification | |
| Drilling capacity | 13 mm (0.51 in) |
| Face milling capacity | 30 mm (1.18 in) |
| End milling capacity | 16 mm (0.63 in) |
| Longitudinal travel | 100 mm (3.94 in) |
| Cross travel | 250 mm (9.84 in) |
| Max. spindle to table | 220 mm (8.66 in) |
| Spindle taper | MT3 |
| T-slot | 10 mm (0.39 in) |
| X axis travel | 300 mm (11.81 in) |
| Y axis travel | 140 mm (5.51 in) |
| Z axis travel | 220 mm (8.66 in) |
| Spindle stroke | 200 mm (7.87 in) |
| Working table size | 460 × 112 mm (18.11 × 4.41 in) |
| Table size | 460 × 110 mm (18.11 × 4.33 in) |
| Dimensions and weight | |
| Machine dimensions | 680 × 400 × 800 mm (L × W × H, approx.) |
| Machine weight | Approx. 180 kg |
| Supply | |
| Product code | EL-CACLE-10880 |
| Manufacturer | Engineering Lab Equipment, Ambala, Haryana, India |
What Is the Miniature Vertical Milling Machine Used For?
Vertical milling uses a cutter turning on a vertical spindle to machine flat faces, slots, steps and pockets, while the same spindle can drill holes with a drill held in a chuck. With the work-piece clamped in the T-slots, the student positions the table with the compound scales and digital readout, selects a spindle speed between 20 and 2500 rpm and feeds the cutter or drill, using the rack and pinion feed when drilling. Tilting the column lets angled holes and faces be machined, while the start/stop switch with emergency stop and the guard with micro switch provide the safety controls during practice.
What to Specify When Ordering
- Quantity — the number of milling machines required.
Frequently Asked Questions
What are the milling and drilling capacities?
The machine has a drilling capacity of 13 mm, a face milling capacity of 30 mm and an end milling capacity of 16 mm, with an MT3 spindle taper.
What speed range does the spindle cover?
A 550 W DC motor with variable speed drive turns the spindle from 20 to 2500 rpm, and the feed speed can be adjusted to suit different work-pieces.
Can the head be tilted for angled work?
Yes. The column tilts so that the work-piece can be drilled and milled at up to ±90° from vertical.
What travel does the bed give?
The bed travels 300 mm on the X axis, 140 mm on the Y axis and 220 mm on the Z axis, and the spindle stroke is 200 mm.
What is supplied with the machine?
It is supplied with a 13 mm chuck accessory kit for adjusting and setting, and the chuck arbor bolt tightens the drilling chuck through the spindle.
Which safety features are fitted?
A safety guard with a micro switch is fitted over the cutting area, and the start/stop switch incorporates an emergency stop button.
