Dial Gauge
Product Code : EL-LEAA-10537
Dial Gauge (code EL-LEAA-10537) is a steel dial gauge used in the laboratory to measure small movements and changes in length. It reads to 0.01 mm over a 10 mm range on a 0-100 graduated dial, and it is light in weight.
Get a quote: use the Add To Cart enquiry button below, or send your quantity and delivery location through the contact page.
Specifications
| Parameter | Detail |
|---|---|
| Material | Steel |
| Reading | 0.01 mm |
| Range | 10 mm |
| Graduation | 0-100 |
| Weight | Light in weight |
| Product code | EL-LEAA-10537 |
| Manufacturer | Engineering Lab Equipment, Ambala, Haryana, India |
What Is the Dial Gauge Used For?
Many soil, concrete and materials tests need small movements measured: the settlement of a sample under load, the swelling of a soil, the penetration of a plunger or the change in length of a specimen. The gauge is clamped to the apparatus so that its plunger rests on the moving part, the dial is set to zero, and as the part moves the pointer turns over the 0-100 graduations, each division representing 0.01 mm. Movements up to the 10 mm range are read directly from the gauge.
What to Specify When Ordering
- Quantity — the number of dial gauges required.
Frequently Asked Questions
What is the reading of the dial gauge?
The gauge reads to 0.01 mm, with the dial graduated from 0 to 100, so each division on the dial equals 0.01 mm of plunger travel.
How far can it measure?
The measuring range is 10 mm, so movements of up to 10 mm can be followed on the one gauge.
What is the gauge made of?
The body is steel and the gauge is light in weight, which keeps the load it places on its mounting bracket small.
Where is a dial gauge used in materials testing?
It is used wherever small movements are measured, such as settlement in consolidation tests, swell of soils, plunger penetration and changes in specimen length.
OEM Manufacturer
Engineering Lab Equipment (Engineering Labs Equipment Pvt Ltd) builds the Dial Gauge at its works in Saha, District Ambala, Haryana (Plot No. 43, Industrial Park, Sector 2, Growth Center). Its general laboratory equipment and accessories such as ovens, baths, balances and measuring tools go to engineering colleges, polytechnics, technical training institutes and research laboratories in India and abroad, and equipment can be made to an institution's own requirements. For tenders and OEM supply, see the Tenders/OEM page.
