Laminar Air Flow

Product Code : EL-LEAA-10999

Laminar Air Flow (code EL-LEAA-10999) is a horizontal uniflow clean bench that passes filtered air across a stainless steel worktable to keep the work area supplied with clean air. Air from the blower passes through non-woven microfibre glass pre-filters and HEPA filters behind a plastic grille, and the cabinet has a thick Perspex front in anodized aluminium framing, UV germicidal and fluorescent lights with separate front controls, and a laminate-finished plywood body on castor wheels.

Get a quote: use the Add To Cart enquiry button below, or send your quantity and delivery location through the contact page.

Specifications

What Is the Laminar Air Flow Used For?

In a horizontal laminar flow bench, room air is drawn in by the blower, cleaned first by the pre-filters and then by the HEPA filters, and blown in a steady, even stream across the worktable towards the operator. Because the clean air sweeps airborne particles away from the work, the bench is used where contamination must be avoided, such as pouring culture media, transferring microbial cultures and preparing sterile samples. The UV germicidal light is switched on between sessions with the cabinet empty, and the fluorescent light illuminates the worktable while work is in progress.

What to Specify When Ordering

• Quantity — the number of cabinets required.

Frequently Asked Questions

What does horizontal uniflow mean?
The filtered air moves in one direction, horizontally across the worktable from the filters at the back towards the open front, rather than downwards from the top.

Which filters are fitted?
Air passes through pre-filters of non-woven microfibre glass pleated media and then through HEPA filters, whose pleats are separated by corrugated aluminium foil and which are protected by a plastic grille.

What lights does the bench have?
It has a UV germicidal light and a fluorescent light, each switched by its own control on the front of the cabinet.

What is the worktable made of?
The worktable is stainless steel sheet, set in a plywood body that is varnished, painted and finished in wood with laminate.

Can the cabinet be moved?
Yes. It stands on castor wheels so that it can be moved within the laboratory, and it runs on a 220/230 V AC, 50 Hz supply.

How is an enquiry for the cabinet placed?
Press the Add To Cart enquiry button here, or write in through the contact page with the number of cabinets and the place they are to be delivered to.

OEM Manufacturer

Engineering Lab Equipment (Engineering Labs Equipment Pvt Ltd) builds the Laminar Air Flow at its works in Saha, District Ambala, Haryana (Plot No. 43, Industrial Park, Sector 2, Growth Center). Its general laboratory equipment and accessories such as ovens, baths, balances and measuring tools go to engineering colleges, polytechnics, technical training institutes and research laboratories in India and abroad, and equipment can be made to an institution's own requirements. For tenders and OEM supply, see the Tenders/OEM page.

Related Laboratory Equipment and Accessories

• Fume Hood Cabinet — chemistry fume extraction cabinet with fiberglass-reinforced polyester liner, remote or built-in blower.
• UV Inspection Cabinet — inspection cabinet with one or 2 long wave UV tubes and UV and fluorescent switching.
• Vacuum Pump — laboratory pump for de-airing water, used with a vacuum gauge and silica gel air drying unit.
• Air Curtain — air curtain for door openings, 2 to 6 ft or 1 to 2 m, with 180 W motor.

See the full Laboratory Equipment and Accessories range or all Civil Engineering Lab Equipment.
