Deep Freezer/ Low Temp. Vertical Model

Product Code : EL-LEAA-11005

Deep Freezer/ Low Temp. Vertical Model (code EL-LEAA-11005) is an upright refrigerated cabinet used to keep samples and materials at low temperature, down to -20 °C. It holds temperature within ±1 °C, has PUF insulation, a polished 304 grade stainless steel interior and a powder coated MS/CRC outer body, uses R 22 and R 134 refrigerant, and needs a 220/230 V mains connection, 50 Hz and single phase.

Get a quote: use the Add To Cart enquiry button below, or send your quantity and delivery location through the contact page.

Specifications

What Is the Deep Freezer/ Low Temp. Vertical Model Used For?

Low temperature storage slows chemical change and microbial growth, so a freezer is used to keep reagents, biological samples and specimens that would deteriorate at room or refrigerator temperature. The user loads the cabinet, sets the temperature and keeps the door closed as much as possible, since every opening lets warm, moist air in; the PUF insulation limits the cold lost through the walls. A bi-metallic thermostat with digital temperature controller cum indicator can be fitted to show and hold the set temperature, and a voltage stabilizer protects the compressor where the mains voltage varies.

What to Specify When Ordering

• Quantity — the number of freezers required.
• Body — powder coated MS/CRC, stainless steel or imported plastic outer body.
• Controls and supply — whether the bi-metallic thermostat with digital temperature controller and a voltage stabilizer are wanted.

Frequently Asked Questions

How cold does the freezer go?
The cabinet reaches temperatures down to -20 °C and holds the set temperature with a stability of ±1 °C.

Which refrigerants are used?
The refrigerants given are R 22 and R 134, used in a compressor-driven cooling system that is rated for continuous duty.

What is the inside of the cabinet made of?
Inside, the cabinet is lined with polished stainless steel sheet of 304 grade, while the outer body is MS or CRC sheet with a powder coated finish.

Are other body materials available?
On request the outer body can be stainless steel or an imported unbreakable plastic sheet instead of the powder coated MS/CRC sheet.

Is a horizontal version mentioned?
The options refer to a horizontal model with a PUF insulated front door opening and a housing of powder coated CRC sheet.

Can a digital temperature display be fitted?
Yes. A bi-metallic thermostat with a digital temperature controller cum indicator is offered as an option, along with a voltage stabilizer.

OEM Manufacturer

Engineering Lab Equipment (Engineering Labs Equipment Pvt Ltd) builds the Deep Freezer/ Low Temp. Vertical Model at its works in Saha, District Ambala, Haryana (Plot No. 43, Industrial Park, Sector 2, Growth Center). Its general laboratory equipment and accessories such as ovens, baths, balances and measuring tools go to engineering colleges, polytechnics, technical training institutes and research laboratories in India and abroad, and equipment can be made to an institution's own requirements. For tenders and OEM supply, see the Tenders/OEM page.

Related Laboratory Equipment and Accessories

• Humidity Chamber Cooling Side Panel — compressor-cooled humidity cabinet for 5 to 50 °C and 40% to 95% humidity, on caster wheels.
• Plant Growth Chamber (Refrigerated) — refrigerated plant growth cabinet, 10 to 50 °C, 60 to 95% humidity, with timed day and night lighting.
• Humidity Chamber — double walled temperature and humidity test cabinet with steam injection, compressor cooling and four inner sizes.
• Laboratory Incubator — double walled thermostatic cabinet with glass window door and glass wool insulation for culture work.

See the full Laboratory Equipment and Accessories range or all Civil Engineering Lab Equipment.

Request a Quote

For this and other laboratory equipment and accessories, schools and colleges can contact Engineering Lab Equipment, a manufacturer, supplier and exporter based in Ambala, India. For a price, send the number of freezers, the body material and any options such as a voltage stabilizer and the delivery location through the contact page; the Add To Cart button on this page also adds the Deep Freezer/ Low Temp. Vertical Model to an enquiry.
