Laboratory Hot Plate

Product Code : EL-LEAA-11000

Laboratory Hot Plate (code EL-LEAA-11000) is an electric heater with a flat cast iron top, used to heat vessels on the laboratory bench. It heats from ambient to 300 °C, its 7.5 inch top is finished in heat resistant paint, and heat is set on an energy regulator marked 0 to 100; a thermostat control and a 304 grade stainless steel body are offered in place of the standard regulator and powder coated mild steel body.

Get a quote: use the Add To Cart enquiry button below, or send your quantity and delivery location through the contact page.

Specifications

What Is the Laboratory Hot Plate Used For?

Hot plates are used to warm and boil solutions, evaporate liquids, dissolve solids and keep samples at a raised temperature without an open flame. The vessel stands on the cast iron top, and the user turns the energy regulator towards 100 for more heat or towards 0 for less; an energy regulator switches the heater on and off for a longer or shorter share of the time rather than holding a fixed temperature. Where a held temperature is wanted, the thermostat option is fitted in place of the energy regulator.

What to Specify When Ordering

• Quantity — the number of hot plates required.
• Control — the standard energy regulator or a thermostat control in its place.
• Body — powder coated mild steel or stainless steel 304 grade.

Frequently Asked Questions

What size is the heating surface?
The heating top is a cast iron plate of 7.5 inch diameter finished with heat resistant paint, set with a gap above the body.

How hot can the plate get?
The plate heats from ambient temperature up to 300 °C, with the heat level set on the energy regulator on the control panel.

How does the 0 to 100 energy regulator work?
At the minimum mark the heater receives the least energy and at the maximum it gives the highest controlled temperature; positions in between give intermediate heat.

Is thermostat control available?
Yes. A thermostat can be supplied in place of the energy regulator, and a 304 grade stainless steel body is also available on request.

What should be listed in an export enquiry?
An export enquiry should list the quantity, destination country, port or city, the preferred delivery terms (for example FOB or CIF), packing requirements and any tender reference number.

OEM Manufacturer

Buyers of the Laboratory Hot Plate deal directly with its maker, Engineering Lab Equipment (Engineering Labs Equipment Pvt Ltd), whose works are at Plot No. 43, Industrial Park, Sector 2, Growth Center, Saha, District Ambala, Haryana, India. The company designs, makes and tests general laboratory equipment and accessories such as ovens, baths, balances and measuring tools, supplies engineering colleges, polytechnics, technical training institutes and research laboratories in India and overseas, and builds to institution-specific requirements on request. Tender details are on the Tenders/OEM page.

Related Laboratory Equipment and Accessories

• Hot Plate Circular — compact round heater with cast iron top and powder coated M.S. body, up to 350 degrees.
• Hot Plate Rectangular — heavy duty rectangular heater with removable MS or SS top and energy regulator, 220/230 volts.
• Heating Mantle — fiberglass element heater for round bottom flasks from 100 ml to 20 litres, up to 450 °C.
• Magnetic Stirrer — heated magnetic stirrer with Teflon coated paddle, stainless steel top and temperature and speed control.

See the full Laboratory Equipment and Accessories range or all Civil Engineering Lab Equipment.

Request a Quote

For this and other laboratory equipment and accessories, schools and colleges can contact Engineering Lab Equipment, a manufacturer, supplier and exporter based in Ambala, India. Quotations are given on request: send the number of hot plates and whether energy regulator or thermostat control is wanted and your delivery location through the contact page, or add the Laboratory Hot Plate to the enquiry cart from this page.

Last updated: October 2026
