Thermal Stability Test Apparatus
Product Code : EL-LEAA-11001
Thermal Stability Test Apparatus (code EL-LEAA-11001) is a heated aluminium block unit used for thermal stability testing of PVC and rubber cable materials. Its double walled body holds a solid round aluminium block drilled for thermal tubes as per IS, heated by a 350 W strip heater and controlled by a microprocessor based PID controller from ambient to 210.1 °C to within ±1 °C.
Get a quote: use the Add To Cart enquiry button below, or send your quantity and delivery location through the contact page.
Specifications
| Parameter | Detail |
|---|---|
| Use | PVC and rubber testing for cables |
| Construction | Double walled |
| Heating block | Solid round aluminium block with holes for thermal tubes as per IS |
| Tube holes | Stainless steel 304 grade, with provision for holes for different tubes |
| Heater | Strip type, 350 W, for uniform temperature |
| Insulation | Ceramic blanket, to minimise heat loss |
| Temperature control | Microprocessor based PID temperature controller cum indicator |
| Temperature range | Ambient to 210.1 °C, working to 210.1 °C continuous |
| Temperature accuracy | ±1 °C or better |
| Digital setting | 1 °C |
| Housing | CRC powder coated mild steel |
| Handle | Handle arrangement for carrying the equipment during a test |
| Power supply | Single phase AC, 220/230 V ±10%, 50 Hz |
| Duty cycle | Continuous |
| Product code | EL-LEAA-11001 |
| Manufacturer | Engineering Lab Equipment, Ambala, Haryana, India |
What Is the Thermal Stability Test Apparatus Used For?
When PVC is heated it begins to break down and give off hydrogen chloride, and the thermal stability test measures how long a compound resists this at a set temperature, which shows how well it is stabilised for service as cable insulation. Prepared samples are placed in thermal tubes that sit in the holes of the heated aluminium block. The operator sets the test temperature on the PID controller, waits for the block to settle, inserts the tubes and times the test, while the solid block keeps all the tubes at the same temperature.
What to Specify When Ordering
- Quantity — the number of units required.
- Tubes — the thermal tube sizes the block holes must take.
Frequently Asked Questions
What temperature range is available?
It heats from ambient to 210.1 °C and can work continuously at that temperature, holding it to ±1 °C or better with a 1 °C digital setting.
How are the samples held during the test?
Samples go in thermal tubes that sit in holes in a solid round aluminium block, drilled as per IS, with provision for holes to suit different tubes.
What heats the block?
A strip type heater of 350 W heats the block, and ceramic blanket insulation in the double walled body keeps heat loss to a minimum.
What does the thermal stability test show?
It shows how long a PVC compound resists breaking down at a set temperature before it releases hydrogen chloride, an indication of how well the material is stabilised against heat.
Can the apparatus be carried?
A handle arrangement is fitted to the unit so that it can be lifted and carried while a test is in progress.
What supply does the unit need?
It runs on a single phase 220/230 V ±10%, 50 Hz supply with a continuous duty cycle, in a CRC powder coated mild steel housing.
OEM Manufacturer
The Thermal Stability Test Apparatus is made by Engineering Lab Equipment (Engineering Labs Equipment Pvt Ltd) at its works at Plot No. 43, Industrial Park, Sector 2, Growth Center, Saha, District Ambala, Haryana, India. The company designs, makes and tests general laboratory equipment and accessories such as ovens, baths, balances and measuring tools for engineering colleges, polytechnics, technical training institutes and research laboratories in India and overseas, and can build equipment to an institution's own requirements. Tender and OEM enquiries are handled through the Tenders/OEM page.
