Triple Beam Balance with Vernier
Product Code : EL-LEAA-10546
Triple Beam Balance with Vernier (code EL-LEAA-10546) is a mechanical beam balance for classroom and industrial weighing. Its three-point base, floating bearing principle and beam design remove the need for level adjustment, and it is built with aluminium pressure castings for the base and beam assembly, agate bearings, steel knife-edges and a stainless steel pan, with a zero adjust knob at the end of the beam.
Get a quote: use the Add To Cart enquiry button below, or send your quantity and delivery location through the contact page.
Specifications
| Parameter | Detail |
|---|---|
| Base | Three-point base, aluminium pressure casting |
| Levelling | Floating bearing principle and beam design remove the need for level adjustment |
| Beam assembly | Aluminium pressure casting |
| Bearings | Agate |
| Knife-edges | Steel |
| Pan | Stainless steel |
| Zeroing | Zero adjust knob at the end of the beam |
| Product code | EL-LEAA-10546 |
| Manufacturer | Engineering Lab Equipment, Ambala, Haryana, India |
What Is the Triple Beam Balance with Vernier Used For?
A triple beam balance weighs by comparison: the object is placed on the pan and poises are slid along three graduated beams until the beam floats level against its mark, and the mass is the sum of the three beam readings. The vernier in its name refers to a vernier scale, which lets a reading be taken between the smallest graduations. Before weighing, the empty pan is brought to zero with the knob at the end of the beam, and no levelling is needed because of the three-point base. Agate bearings and steel knife-edges let the beam swing freely, so small differences in load show clearly.
What to Specify When Ordering
- Quantity — the number of vernier beam balances required.
Frequently Asked Questions
Does the balance need levelling before use?
No levelling adjustment is needed. The balance stands on a three-point base and uses a floating bearing principle and beam design, which together take the place of levelling.
How is the balance zeroed?
A zero adjust knob at the end of the beam is turned until the empty balance reads zero, which is quickly done before each weighing session.
What materials is it built from?
The base and beam assembly are aluminium pressure castings, the bearings are agate, the knife-edges are steel and the weighing pan is stainless steel.
What does the vernier add to a triple beam balance?
A vernier scale lets the position of the poise be read between the smallest graduations, so the mass can be read more finely than from the beam markings alone.
How does a triple beam balance weigh an object?
The load on the pan is balanced by sliding poises along three graduated beams until the pointer rests at zero; the mass is the total of the three beam readings.
OEM Manufacturer
Engineering Lab Equipment (Engineering Labs Equipment Pvt Ltd) builds the Triple Beam Balance with Vernier at its works in Saha, District Ambala, Haryana (Plot No. 43, Industrial Park, Sector 2, Growth Center). Its general laboratory equipment and accessories such as ovens, baths, balances and measuring tools go to engineering colleges, polytechnics, technical training institutes and research laboratories in India and abroad, and equipment can be made to an institution's own requirements. For tenders and OEM supply, see the Tenders/OEM page.
