Tablet Hardness Tester

Product Code : EL-LEAA-11010

Tablet Hardness Tester (code EL-LEAA-11010) is a microprocessor operated instrument with a digital display used to measure the breaking point, or hardness, of tablets of all types. It can test up to 25 tablets at one time, gives a hardness range of 5 to 500 N with a measuring range of 1 N to 300 N, and takes tablets of 0 to 25 mm width, 0 to 10 mm thickness and 45 mm diameter.

Get a quote: use the Add To Cart enquiry button below, or send your quantity and delivery location through the contact page.

Specifications

What Is the Tablet Hardness Tester Used For?

Tablet hardness, or breaking force, is the force needed to crush a tablet across its diameter; tablets that are too soft break during packing and handling, while very hard tablets may not disintegrate as intended. Each tablet is placed between the jaws, the instrument applies an increasing load until the tablet breaks, and the breaking force is shown on the digital display in newtons. The operator starts each test from the keypad and can work through a set of up to 25 tablets, which gives a sample for checking consistency from batch to batch.

What to Specify When Ordering

• Quantity — the number of testers required.
• Tablet size — the width, thickness and diameter of the tablets to be tested, within 25 mm, 10 mm and 45 mm.

Frequently Asked Questions

What force range does it measure?
The hardness range is given as 5 to 500 N and the measuring range as 1 N to 300 N, with results shown on a digital display.

How many tablets can be tested in one run?
The tester takes a maximum of 25 tablets at one time, and it can measure the hardness strength of all types of tablets.

What tablet sizes fit the tester?
Tablets from 0 to 25 mm wide and 0 to 10 mm thick can be tested, and the diameter is given as 45 mm.

Why is tablet hardness tested?
A tablet must be strong enough to survive coating, packing and transport, but not so hard that it fails to break up after it is swallowed, so hardness is checked during production.

How is the tester operated?
It is microprocessor operated through a keypad, with readings shown on a digital display, and it is housed in a powder coated mild steel body.

OEM Manufacturer

The Tablet Hardness Tester is made by Engineering Lab Equipment (Engineering Labs Equipment Pvt Ltd) at its works at Plot No. 43, Industrial Park, Sector 2, Growth Center, Saha, District Ambala, Haryana, India. The company designs, makes and tests general laboratory equipment and accessories such as ovens, baths, balances and measuring tools for engineering colleges, polytechnics, technical training institutes and research laboratories in India and overseas, and can build equipment to an institution's own requirements. Tender and OEM enquiries are handled through the Tenders/OEM page.

Related Laboratory Equipment and Accessories

• Friability Test Apparatus — acrylic drum tablet friability tester, single or double drum, with revolution counter and 0 to 60 minute timer.
• Bulk Density Apparatus Construction/Housing — motor-driven bulk density tester with 150 ml cylinder, 2-cylinder collar and 999 count digital counter.
• Digital Vernier Caliper — hardened stainless steel electronic caliper for outer, inner, depth and step readings with inch/metric switching.

See the full Laboratory Equipment and Accessories range or all Civil Engineering Lab Equipment.

Request a Quote

For this and other laboratory equipment and accessories, schools and colleges can contact Engineering Lab Equipment, a manufacturer, supplier and exporter based in Ambala, India. To ask for a quotation, send the number of testers and the size of the tablets to be tested and your delivery location through the contact page, or use the Add To Cart enquiry button on this page.
