Portable Core Cutting Drilling Machine Petrol

Product Code : EL-RTLE-10497

Portable Core Cutting Drilling Machine Petrol (code EL-RTLE-10497) is a compact, wheel-mounted core drill that cuts cores up to 200 mm diameter from concrete, asphalt and similar hard construction materials. A 6.5 HP petrol engine drives the drill head on a vertical support column, a ball screw mechanism controls drilling pressure and gives rapid return, and a water spraying assembly is mounted on the machine, which weighs approximately 100 kg.

Get a quote: use the Add To Cart enquiry button below, or send your quantity and delivery location through the contact page.

Specifications

What Is the Portable Core Cutting Drilling Machine Petrol Used For?

Cores drilled from a slab, pavement or structure give specimens of the material as it actually is in place, which are then measured and tested in the laboratory. Because the petrol engine needs no mains supply, the machine is wheeled to the test location on its base frame, levelled and fixed, and the drill head is fed down the column with the ball screw so that the drilling pressure stays under control; when the core is cut, the head is returned rapidly. Water from the spraying assembly cools the cutting edge and flushes away cuttings. The standard listed for it is EN 12697-27.

What to Specify When Ordering

• Quantity — the number of machines required.
• Core size — the core diameters to be drilled, up to 200 mm.

Frequently Asked Questions

What core size can the Portable Core Cutting Drilling Machine Petrol cut?
It cuts cores up to 200 mm in diameter from concrete, asphalt and similar hard construction materials.

What powers the machine?
The drill head/motor assembly uses a 6.5 HP petrol engine, so the machine can be run where there is no mains electricity.

How is drilling pressure controlled?
A ball screw mechanism gives close control of the drilling pressure while the core is cut and a rapid return of the drill head once drilling is complete.

How is the machine moved and set up on site?
The assembly sits on a wheel-mounted metal base frame that can be levelled and fixed in position during operation, and the machine weighs approximately 100 kg.

Is water used during drilling?
Yes. A water spraying assembly is mounted on the machine to supply water at the cutting point while the core is being drilled.

Which standard is listed for it?
The standard listed for it is EN 12697-27, and the machine is used for taking cores from asphalt, concrete and similar materials.

OEM Manufacturer

The Portable Core Cutting Drilling Machine Petrol is made by Engineering Lab Equipment (Engineering Labs Equipment Pvt Ltd) at its works at Plot No. 43, Industrial Park, Sector 2, Growth Center, Saha, District Ambala, Haryana, India. The company designs, makes and tests rock testing equipment for specimen preparation, strength and durability tests for engineering colleges, polytechnics, technical training institutes and research laboratories in India and overseas, and can build equipment to an institution's own requirements. Tender and OEM enquiries are handled through the Tenders/OEM page.
