Microprocessor Photo Colorimeter
Product Code : EL-ETLE-10972
Microprocessor Photo Colorimeter (code EL-ETLE-10972) is a filter instrument for reading percent transmittance, absorbance and concentration of coloured liquid samples, with 8 standard glass filters covering 400 to 700 nm. It shows 0 to 100% T, 0 to 1.99 Abs and 0 to 999 concentration on a 3.5 digit bright red 7 segment LED display, uses a 6.3 V, 0.3 Amp tungsten lamp, needs a minimum sample volume of 1 ml and stores 3 standard concentrations.
Get a quote: use the Add To Cart enquiry button below, or send your quantity and delivery location through the contact page.
Specifications
| Parameter | Detail |
|---|---|
| Readings | % transmittance, absorbance, concentration |
| % transmittance | 0 to 100% |
| Absorbance | 0 to 1.99 |
| Concentration | 0 to 999 |
| Resolution | 1% T, 0.01 Abs, 1 conc., 0.01 K factor |
| Display | 3.5 digit bright red 7 segment LED |
| Keyboard | 5 keys, soft touch membrane type |
| Auto zeroing | Available for Abs, and 100% for %T |
| Light source | 6.3 V, 0.3 Amp tungsten lamp |
| Filters | 8 standard glass filters, wavelength range 400 to 700 nm |
| Minimum sample volume | 1 ml |
| Memory | Storage of 3 standard concentrations |
| Power | 230 V ±10%, 50 Hz AC |
| Product code | EL-ETLE-10972 |
| Manufacturer | Engineering Lab Equipment, Ambala, Haryana, India |
What Is the Microprocessor Photo Colorimeter Used For?
A colorimeter measures how strongly a coloured solution absorbs light of a chosen colour, and is used for routine tests in water, food and clinical laboratories where a reagent turns the substance of interest into a coloured product. The operator fits the glass filter whose colour is complementary to that of the solution, sets zero absorbance and 100% T on a blank, and then reads the samples. Once a standard of known strength has been read, the instrument can display concentration directly through its K factor, and up to 3 standard concentrations can be kept in memory, so repeated tests need less setting up.
What to Specify When Ordering
- Quantity — the number of colorimeters required.
Frequently Asked Questions
How is the wavelength selected?
The colorimeter uses 8 standard glass filters spanning 400 to 700 nm; the filter chosen is the one whose colour the sample absorbs most.
Can it read concentration directly?
Yes. Besides %T and absorbance it shows concentration from 0 to 999, using a K factor resolved to 0.01, and it can store 3 standard concentrations.
How small a sample can be measured?
The minimum sample volume is 1 ml, which helps when only a small amount of sample or reagent is available.
How is the instrument zeroed?
Auto zeroing is available for absorbance and for setting 100% on the transmittance scale, so the blank reading is set automatically before samples are measured.
What display and controls does it have?
Results appear on a 3.5 digit bright red 7 segment LED display, and the instrument is operated from a 5-key soft touch membrane keyboard.
What lamp and power supply are used?
A 6.3 V, 0.3 Amp tungsten lamp is the light source, and power is taken from a 230 V ±10%, 50 Hz AC supply.
OEM Manufacturer
Engineering Lab Equipment (Engineering Labs Equipment Pvt Ltd) builds the Microprocessor Photo Colorimeter at its works in Saha, District Ambala, Haryana (Plot No. 43, Industrial Park, Sector 2, Growth Center). Its environmental testing instruments for water, soil and air analysis go to engineering colleges, polytechnics, technical training institutes and research laboratories in India and abroad, and equipment can be made to an institution's own requirements. For tenders and OEM supply, see the Tenders/OEM page.
Related Environmental Testing Equipment
- Digital Spectrophotometer — 340 to 960 nm LED-readout spectrophotometer with halogen lamp and silicon photodiode detector.
- Jar Test Apparatus — variable speed 20 to 100 RPM paddle stirrer for coagulation and floc tests in 1000 ml beakers.
- COD Digestion Apparatus — 15-tube aluminium block heater to 180 °C with digital controller and 120 minute alarm timer.
See the full Environmental Testing Lab Equipment range or all Civil Engineering Lab Equipment.
Request a Quote
For this and other environmental testing lab equipment, schools and colleges can contact Engineering Lab Equipment, a manufacturer, supplier and exporter based in Ambala, India. For a price, send the number of colorimeters required and the delivery location through the contact page; the Add To Cart button on this page also adds the Microprocessor Photo Colorimeter to an enquiry.
