Water Still

Product Code : EL-LEAA-11017

Water Still (code EL-LEAA-11017) is a wall-mounted electric still used to produce pyrogen free distilled water for the laboratory. Its body, condenser tube and jacket are 304 grade stainless steel, a kettle type element heats the water, and the condenser tube can be dismantled by removing the wing nut that holds it and the jacket to the wall bracket; it takes a 220/230 V ±10%, 50 Hz single phase supply.

Get a quote: use the Add To Cart enquiry button below, or send your quantity and delivery location through the contact page.

Specifications

What Is the Water Still Used For?

Distillation purifies water by boiling it and condensing the steam, leaving dissolved salts and most other impurities behind in the boiler, so the distillate is suitable for preparing reagents, rinsing glassware and other work where tap water would affect results. In use, cooling water flows through the jacket around the condenser tube while the kettle element boils the water in the still; the steam condenses in the tube and the distilled water runs out to a collecting vessel. The water level is checked at regular intervals, and the condenser can be taken off its wall bracket for cleaning.

What to Specify When Ordering

• Quantity — the number of stills required.

Frequently Asked Questions

What is the still made of?
The body is 304 grade stainless steel, and the condenser tube and jacket are made from 304 grade stainless steel sheet or pipe.

How is the still mounted?
It is fixed to the wall on a wall bracket, with the condenser and jacket held to the bracket by a wing nut.

Can the condenser be cleaned?
Yes. Removing the wing nut releases the condenser and jacket from the wall bracket, so the condenser tube can be dismantled for cleaning.

How does a water still work?
Water in the still is boiled by the heating element, the steam passes into the condenser tube, and cooling water in the surrounding jacket turns it back into liquid, which runs off as distilled water.

What attention does the still need in use?
The water level is checked at regular intervals while the still is working, and the element is fed from 220/230 V ±10%, 50 Hz single phase mains.
