Laboratory Digital Planetary Mixer
Product Code : EL-STLE-10406
Laboratory Digital Planetary Mixer (code EL-STLE-10406) is a table mounted mixer with planetary mixing action for preparing asphalt mixes in the laboratory. It has a 5 litre bowl, a 370 W motor, user defined planetary speeds of 5 to 65 rpm and whisk speeds of 12 to 149 rpm set from a 2 × 16 character display and keyboard, and a front grill that stops the machine when opened.
Get a quote: use the Add To Cart enquiry button below, or send your quantity and delivery location through the contact page.
Specifications
| Parameter | Detail |
|---|---|
| Use | Mixing asphalt mixes; can be used as part of a Superpave performance based testing programme |
| Mounting | Table mounted |
| Mixing action | Planetary |
| Bowl and whisk | Removable; both supplied with the mixer |
| Controls | Display and keyboard interface; mixing speed selectable and adjustable during mixing |
| Display | Alphanumeric, 2 × 16 characters |
| Planetary speeds | User defined from 5 to 65 rpm |
| Whisk speed | User defined from 12 to 149 rpm |
| Bowl capacity | 5 litres |
| Power | 370 W |
| Safety | Front grill stops the machine automatically when opened |
| Overall dimensions | 465 × 540 × 620 mm (l × d × h) |
| Weight | 35 kg (approx.) |
| Product code | EL-STLE-10406 |
| Manufacturer | Engineering Lab Equipment, Ambala, Haryana, India |
What Is the Laboratory Digital Planetary Mixer Used For?
Asphalt specimens for laboratory testing are made from aggregate and bitumen that must be blended until every particle is evenly coated, and the mix has to be repeated the same way for each batch. The aggregate and binder are placed in the 5 litre bowl, the whisk is fitted, and the operator sets the planetary and whisk speeds on the keyboard, adjusting them while the mixer runs if needed. The planetary action carries the turning whisk around the bowl so that it reaches all of the mix, and the front grill has to stay closed for the machine to run. The mixed material then goes on to compaction and performance tests.
What to Specify When Ordering
- Quantity — the number of planetary mixers required.
Frequently Asked Questions
What is the mixer used for?
It is used for mixing asphalt mixes in the laboratory, and it can form part of a Superpave performance based testing programme.
What speeds can be set?
Planetary speed is user defined from 5 to 65 rpm and whisk speed from 12 to 149 rpm, and the speed can be changed during mixing.
What is the bowl capacity?
The bowl holds 5 litres, and the mixer is supplied complete with the bowl and whisk, both of which are removable.
What safety protection is fitted?
Opening the front grill automatically stops the machine, which protects the operator from the moving whisk during mixing.
What are the power rating and size?
The motor is rated at 370 W, the overall dimensions are 465 × 540 × 620 mm (l × d × h) and the weight is approximately 35 kg.
How can the planetary mixer be ordered?
Place an enquiry with the Add To Cart button on this page, or send the quantity required and the delivery location using the contact page.
OEM Manufacturer
Buyers of the Laboratory Digital Planetary Mixer deal directly with its maker, Engineering Lab Equipment (Engineering Labs Equipment Pvt Ltd), whose works are at Plot No. 43, Industrial Park, Sector 2, Growth Center, Saha, District Ambala, Haryana, India. The company designs, makes and tests soil testing equipment for classification, compaction, density, shear and consolidation tests, supplies engineering colleges, polytechnics, technical training institutes and research laboratories in India and overseas, and builds to institution-specific requirements on request. Tender details are on the Tenders/OEM page.
Related Soil Testing Equipment
- High Speed Stirrer — 230 V laboratory stirrer running at about 4000 RPM, with dispersion or baffle cup.
- Particle Size Analysis Set, Hydrometer Method — hydrometer sedimentation set with six 1000 ml cylinders, 151H hydrometer, heated tank and stirrer.
- Speedy Moisture Testers — carbide pressure moisture tester for soil, 0-25% gauge, with balance in wooden case.
- Standard Compaction Test — standard compaction set with 1000 cc steel mould, collar, base plate and 2.6 kg rammer.
See the full Soil Testing Lab Equipment range or all Civil Engineering Lab Equipment.
Request a Quote
For this and other soil testing lab equipment, schools and colleges can contact Engineering Lab Equipment, a manufacturer, supplier and exporter based in Ambala, India. Quotations are given on request: send the number of planetary mixers required and your delivery location through the contact page, or add the Laboratory Digital Planetary Mixer to the enquiry cart from this page.
