Gas Charging Trainer
Product Code : EL-RAACLE-10793
Gas Charging Trainer (code EL-RAACLE-10793) is a portable bench top unit on which students learn to empty and evacuate a refrigeration unit with a vacuum pump and then charge it with the correct amount of refrigerant. It has a vacuum pump and a filling cylinder holding 1000 g of R134a, manometers for intake, delivery and cylinder pressure, a vacuum gauge reading 0 to 1000 mbar, and intake and delivery connections.
Get a quote: use the Add To Cart enquiry button below, or send your quantity and delivery location through the contact page.
Specifications
| Parameter | Detail |
|---|---|
| Purpose | Emptying and evacuating a refrigeration unit with a vacuum pump, then charging it with the correct amount of refrigerant |
| Type | Portable bench top unit |
| Main items | Vacuum pump and filling cylinder |
| Pressure instruments | Manometers for intake, delivery and cylinder pressure; vacuum gauge |
| Refrigerant manometers | Intake and delivery pressure, with temperature scale for refrigerant R134a |
| Connections | For intake and delivery pressure |
| Filling cylinder | 1000 g R134a |
| Measuring ranges | |
| Intake pressure | -1 to 10 bar |
| Delivery pressure | -1 to 30 bar |
| Vacuum | 0 to 1000 mbar |
| Cylinder pressure | -1 to 25 bar |
| Learning content | |
| Evacuation | Evacuating a refrigeration system |
| Charging | Charging a refrigeration system |
| Power, dimensions and weight | |
| Power supply | 230 V, 50 Hz, 1 phase; or 230 V, 60 Hz, 1 phase |
| Dimensions | Approx. 1000 × 700 × 1400 mm (L × W × H) |
| Weight | Approx. 110 kg |
| Supply | |
| Product code | EL-RAACLE-10793 |
| Manufacturer | Engineering Lab Equipment, Ambala, Haryana, India |
What Is the Gas Charging Trainer Used For?
Before a refrigeration system is charged, air and moisture have to be pumped out, because they raise the condensing pressure and moisture can freeze or form acids in the circuit. Students first empty the system, connect the vacuum pump and pull the circuit down to vacuum, watching the 0 to 1000 mbar gauge. They then charge refrigerant from the filling cylinder until the correct amount is in the system, checking the intake and delivery manometers, whose R134a temperature scales show the matching saturation temperatures.
What to Specify When Ordering
- Quantity — the number of gas charging units required.
- Mains version — built for 50 Hz or for 60 Hz, at 230 V and one phase.
Frequently Asked Questions
What skills does the Gas Charging Trainer teach?
It teaches how to empty a refrigeration unit, evacuate it with a vacuum pump, and then charge it with the correct amount of refrigerant.
Which gauges are fitted?
There are manometers for intake, delivery and cylinder pressure, a vacuum gauge, and intake and delivery manometers with a temperature scale for refrigerant R134a.
How much refrigerant does the filling cylinder hold?
The filling cylinder holds 1000 g of R134a, and its pressure is read on a manometer covering -1 to 25 bar.
What pressure ranges are covered?
Intake pressure reads -1 to 10 bar, delivery pressure -1 to 30 bar, vacuum 0 to 1000 mbar and cylinder pressure -1 to 25 bar.
Why must a system be evacuated before charging?
Air and moisture left in the circuit raise the condensing pressure, and moisture can freeze at the expansion device or react to form acids, so both are removed under vacuum first.
How can the trainer be ordered?
Request it with the Add To Cart enquiry button on this page, or give the quantity and delivery location on the contact page.
